Four-digit display 0.01 V/0.001 A
1.WPS1602H/B Programmable DC power supply with power display 160V 2A
2.WPS1203H/B Programmable DC power supply with power display 120V 3A
3.WPS3010H/B Programmable DC power supply with power display 30V 10A
4.WPS605H/B Programmable DC power supply with power display 60V 5A
5.WPS305H/B Programmable DC power supply with power display 30V 5A
6.APS305H Programmable DC power supply with power display 30V 5A With three group storage function
7.APS3010H Programmable DC power supply with power display 30V 10A With three group storage function
8.APS605H Programmable DC power supply with power display 60V 5A With three group storage function
9.APS1203H Programmable DC power supply with power display 120V 3A With three group storage function
10.APS1602H Programmable DC power supply with power display 160V 2A With three group storage function
1.Small size, light weight and high power density.
|
Output Power |
150W/300W/320W/360W |
|
Output voltage |
0~30V/60V/120V/160V |
|
Output current |
0~2A/3A/5A/10A |
|
working environment |
|
|
input voltage:AC 230V/115V±10%;50Hz/60Hz |
|
|
Working temperature:0℃～40℃;relative humidity:<80%RH |
|
|
Storage temperature:-10℃～70℃;relative humidity:<70%RH |
|
|
Constant voltage CV |
|
|
Voltage stability:0.1%±3mV |
|
|
Load stability: 0.2%±3mV |
|
|
Ripple voltage:≤0.5% Vp-p |
|
|
0 to rated voltage continuously adjustable |
|
|
constant current CC |
|
|
Current stability:0.1%±3mA |
|
|
Load stability: 0.2%±3mA |
|
|
Ripple current:≤0.5% Vp-p |
|
|
Recovery time:≤500μS |
|
|
Temperature coefficient:≤100ppm/℃ |
|
|
0 to rated current continuously adjustable |
|
2. Mobile phonemaintenance, computermaintenance, electrical appliance maintenance,Car DVD, car audio.
3. Product aging, electroplating,such as resistors, capacitors, relays, DC motors, LEDs, etc.
4. Charge the battery.
5. Laboratory, scientific research teaching,factory, maintenance power supply.school laboratories scientific research and production line use
6. All other occasions requiring DC power supply.
1x DC power supply
1x power cord (EU,US,UK,AU)We will configure the correct plug according to your country (you can consult customer service)
1x Test line
1x Instructions
Q: Is the input voltage of the power supply 220V or 110V?
A: There is an adjustable switch on the back of the power supply. If the input voltage in your area is 110V, please turn the switch to 115V to use it. If the input voltage in your area is 220V, please turn the switch to 230V to use it. The factory default value of power input voltage is adjusted to 230V. (Please remember not to adjust it wrong, otherwise it will burn out the power supply).
Q: Can I configure the European standard plug m?
A: We have EU UK US AU, etc. will be configured according to your country and region the correct plug can consult customer service
Q: can be charged to the battery battery?
A: can be charged
Q: What is wrong with the power supply fan does not work?
A: The fan is intelligent temperature control when the internal higher than 50C ° will automatically open the fan heat
Q: When this power is turned off and on again, does it remember the last setting?
A: It is controlled by the adjustment knob, as long as you do not move the adjustment knob, it will turn on at the previous setting.
window.adminAccountId=252901250;
Cassey Odle –
I have been behind another for a long time and finally I made up my mind, it looks good how little I have tasted it well. Truth. Shipping surprised me 3 days, very fast.
Eleri Barnes –
very nice!! works great!
Daanyal Shepard –
This power supply is not programmable. The manual describes an rs232 interface which is optional but absent on this model, the port opening covered with a sticker. So this power supply is not programmable at all, look elsewhere if that’s what you need.
Emmanuel Gillie –
Very happy and grateful for the shipping so fast, excellent source, I liked it very much
Shanda Gatling –
Everything is fine 🙂 Thank you seller. I recommend to purchase. Two days to hakassia 🙂 never delivered so quickly
Durante Sciara –
Super fast shipping, the item as described by the seller, the source has very acceptable accuracy. Satisfied with the team ..
Ildefonso Sollami –
looks good strong and not massive,
accurate enough for me.
came pretty fast and well packed
Tandy Hoyte –
Arrived on time, well packed and brand new, excellent condition, meet what I ordered in voltage, excellent seller
Gérald Courbet –
It is perfect. It came within 3 working days from Poland to Slovakia. Is even smaller than I thought, light, beeps by setting the output values. I tried just check voltage, it is quite precise (-0.05V by 15V), USB works independently from settings (atleast you can not turn it off by OUTPUT button), I tried short circuit, it shows red sign on display. For now I am satisfied.
Derrick Sclafani –
The block of Zhivlennya pratsyu good, the wind and sound in the normal, I will write everything, I recommend it Compact
